| Product Name: | Downspout Roll Forming Machine | Power: | 7.5kw+5.5kw+2.2kw |
|---|---|---|---|
| Steel Thickness: | 0.5-0.7mm | Decoiler: | Manual |
| Station: | 20 Stations | Roller Material: | 45# Steel |
| Drive: | Single Chain | Container Need: | 1X40GP |
| High Light: | Downspout Roll Forming Machine,Steel Pipe Making Machine |
||
Down pipe roll forming machine
Description:
This down pipe forming machine is used in manufacturing rectangle or round down pipe with close entrance, and its specific dimension is made at customers' requirements. The main components of this device are decoiler, roll former, cutting device, control cabinet, and pipe bending machine, etc. The machine is designed logically and possesses high quality forming. Controlled by PLC, this down pipe forming machine is quite convenient to operate. The processing flow of this machine is as follows: decoiling-guiding-forming-cutting-pipe bending.
Properties:
This machine adopts automatic PLC control and touch screen operation. And it has high speed forming process and makes little noise. The equipment adopts welded frame of high intensity. After fine finish, forming rollers get heat treatment before chromeplate. So this equipment has features of stable performance and long service life.
Main specification
| No | Specification of the material | |
|
1
|
Suitable Material | Colored Steel plate, Galvanized steel |
|
2
|
Width of the raw material | based on profile drawing |
| 3 | Thickness | 0.5-0.7mm |
Profile drawing:
The Chart of Process Flow
Manual Uncoiler—Roll Forming—Cutting—out table
Specification of Components
| No | Technical Specification & Remark | |
| 1 |
Manual Uncoiler
|
|
| 2 |
Main Roll Forming Machine
|
|
| 3 |
Machine structure:
|
|
| 4 |
Hydraulic cutting system
|
|
| 5 |
Hydraulic System
|
|
| 6 |
Computer Control Cabinet
|
|
| 7 |
Out table
|
|
| 8 |
Bending machine
|
|
6. Warranty
1: Guaranteed against malfunctions due to manufacturing defects for 1 year after date of shipment. Repairs will be made free of charge.
2: Repairs will not be performed free of change even during the guarantee period in the follow circumstances
- Damage occurs due to a natural disaster
- Malfunction occurs due to user error
- Malfunction occurs due to modifications
- Malfunction occurs due to further movement or shipment after installation
3:Air ticket, transportation cost, hotel, meals and 100$ per day shall be for purchaser’s account if manufacturer’s engineer has to be send to purchaser’s factory to maintain the machine during the guarantee period.
