Concrete Door Frame Shutter Roll Forming Machine 1.0mm thickness Single Chain Driven

Basic Information
Place of Origin: China
Brand Name: Saibo
Certification: CE/IS09001/SGS
Model Number: YX55-123
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Suitable for ocean shipment
Delivery Time: 50 working days after received deposit
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300 sets per year
Contact Now
Detail Information
Decoiler: Manual Product Name: Door Frame Roll Forming Machine
Power: 7.5KW+5.5KW Roller Material: #45 Forged Steel With Chrome
Station: 17 Stations Usage: Door Application
Drive: Single Chain Container Need: 1X40GP

Product Description

Door Frame Roll Forming Machine



Profile:

All of our machine profile is customized, below profile is only for your reference.

1. Coil width: according the profile

2. Effective width: according the profile

3. Thickness: 1.0mm

Concrete Door Frame Shutter Roll Forming Machine 1.0mm thickness Single Chain Driven



Layout:

Concrete Door Frame Shutter Roll Forming Machine 1.0mm thickness Single Chain Driven

Manual de-coiler—Feeding—Roll Forming—Cutting—Out table



Specifications:

Item NO



Description



Offered specification

1 Roll Forming Machine

Door frame



2 Coil width According the profile
3 Rolling Speed 12-15m/min(not include cutting & time)
4 Rolling Thickness 1.0mm GI
5 Control System PLC (Panasonic) as list in the note
6 Un Coiler 3T manual decoiler
7 Roller Stations About 17 stations (according the final design)
8 Roller Material 45# forge steel, coated with chrome
9 Shaft Material and DIA ¢65mm, material is 45# forge steel
10 Post cutting Hydraulic cutting after forming
11 Maim Motor Power 7.5kw
12 Hydraulic Station Power 5.5kw
13 Hydraulic Pressure 12-16Mpa adjustable
14 Material Of Cutting Cr12Mov quenching 58-62℃
15 Sturcture Of The Stations Wall panel
16 Tolerance 3m+-1.5mm
17 Electric Source

380V, 50HZ,3 phase

According to customer’s require



18 Way Of Drive By chain
19 Color Of The Machine Yellow and blue
20 Size of the machine L*W*H about 8.0m*1m*1.2m
21 Container Need 1x40 feet


Main Features

1. Simple structure in linear type ,easy in installation and maintenance.

2. Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.

3. Running in a high automatization and intellectualization, no pollution

4. No need foundation, easy operation









Contact Details
Ms.Nancy

WhatsApp : 8613921223200
