Chain Driven Floor Deck Roll Forming Machine 0.8-1.5mm Thickness 40GP Container

Basic Information
Place of Origin: China
Brand Name: Saibo
Certification: CE/ISO
Model Number: YX80-300-600
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Suitable for ocean shipment
Delivery Time: 70 working days after received deposit
Payment Terms: T/T, L/C
Supply Ability: 300 sets per year
Contact Now
Detail Information
Product Name: Floor Deck Roll Forming Machine Power: 22kw X2+5.5kw
Size Of Purlin: YX80-300-600 Steel Thickness: 0.8-1.5mm
Decoiler: Manual Or Hydraulic Station: 34 Stations
Roller Material: ASTM1045 Chrome Plated Surface With Hardness, CNC Drive: By Chain

Product Description

1. Specification of the material


1. Suitable material: PI/ PPGI

2. Wdith of the raw material: 1000mm

3. Thinckness: 0.8-1.5mm





2. Machine Detailed Parameters

1



Roll Forming Machine YX80-300-600

2



Machine structure Wall panel

3



Total power

Motor power-22kw x2kw

Hydraulic power-5.5kw

4



Roller stations About 34 stations

5



Productivity

0-15m/min

6



Drive system By chain

7



Diameter of shaft ¢76mm solid shaft

8



Voltage 380V 50Hz 3phases (Customized)

9



Color Of The Machine Yellow and blue

10



Container need 40GP container

11



Deliver Time 70 days

12



Terms Of Payment 30%T/T 70% pay before shipment



3. Profile drawing

Chain Driven Floor Deck Roll Forming Machine 0.8-1.5mm Thickness 40GP Container



4. The Chart of Process Flow

Chain Driven Floor Deck Roll Forming Machine 0.8-1.5mm Thickness 40GP Container





5. Specification of Components

(1) 5T Manual Un-coiler

  • Width of feeding: 1250mm
  • Capability: 5 Ton
  • Inter diameter: 500-590mm
  • Maximal out diameter: 1500mm
  • Mode of expand &fight: inner expand &fight by manual
  • Way of feeding: manual



(2) Main Roll Forming Machine

  • Roller material: ASTM1045 chrome plated surface with hardness, CNC
  • Shaft diameter: ¢90mm
  • Shatf material: SAE1045 with quenching and tempering
  • Machine structure: wall panel



(4) Hydraulic cutting system

  • Cutting after forming: Cut the sheet after roll forming to required length
  • Uses two hydraulic cylinders for operation.
  • Material of blade:Cr12, 58-62 HRC hardness
  • Cutting power by hydraulic,5.5KW
  • Working pressure: 12Mpa adjustable
  • Length measuring: Automatic encoder length measuring
  • Tolerance of length: +/- 1.5mm for each piece end product



(5) Computer Control Cabinet

  • Programmable setting of profile length and quantity
  • Operating system language: English and Chinese
  • Computer used to control length & quantity. Machine will automatically cut to length and stop when required quantity is achieved
  • PLC: Panasonic or customerization
