| Product Name: | High Speed Stud And Track Roll Froming Machine | Main Power: | 30KW,, ESTUN |
|---|---|---|---|
| Steel Thickness: | 0.4-1.15mm | Decoiler: | 5T Hydraulic Double Head Decoiler |
| Station: | 18 Stations + One Station For Rectify | Roller Material: | CR12 Chrome Plated, HRC58-62 |
| Drive: | By Gear Box | Line Speed: | 70m/min |
| Warranty: | 1 Year | Color: | Bule And Yellow |
| High Light: | Ceiling Roll Forming Machine 30KW,Ceiling Roll Forming Machine 70m/Min,Hydraulic Speed Ceiling Roll Forming Machine |
||
High Speed Stud and Track Roll Froming Machine
1. Specification of the material
| 1 | Suitable Material | Galvanized steel 350Mpa-550Mpa |
| 2 | Width of the raw material | According to the final profile |
| 3 | Thickness | 0.4-1.15mm |
2. Machine Detailed Parameters
| 1 | Roll Forming
|
High Speed Stud and Track Roll Froming Machine
|
| 2 | Machine structure
|
Wire-electrode cutting |
| 3 | Total power |
Motor power-30kw Hydraulic power-18.5kw Servo power-5.5kw |
| 4 | Roller stations |
About 18 stations + one station for rectify
|
| 5 |
Productivity
|
70m/min |
| 6 |
Drive system
|
By gear box |
| 7 |
Diameter of shaft
|
￠60mm ,40CR tempering |
| 8 |
Voltage
|
380V 50Hz 3phases (Customized) |
| 9 |
Color Of The Machine
|
Yellow and blue |
| 10 |
Deliver Time
|
70 days |
| 11 |
Terms Of Payment
|
30%T/T 70% pay before shipment |
3. Profile drawing
4. The Chart of Process Flow
5. Specification of Components
(1) 5T Double head hydraulic decoiler
(2) Main Roll Forming Machine
(3) Machine Structure
(4) Track punching& cutting system
(5) Computer Control Cabinet
Usage:
a. Put the raw material(steel plate) through the beach to manufacture and process,it can guarantee that the products are neat, parallel and everything is uniformity.Please refer to the equipment regulation to know the function of locate angle iron.
b. In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain
transmission,roller was chromed which can keep the molding plate surface smooth and not easy to be marked whenit is working
c. Feature : Ensure stability , precision and lifetime.
Advanced hydraulic drive, automatic punching and cutting after forming, no distorting or wasting, high level safety factor.
