High Speed C16 Trapezoidal Roll Forming Machine with 23 Rows Rollers and 0.3-0.6mm Processable Thickness for Steel Wall Plate Profiling

Detail Information

Product Description

Detail Information

Total Machine Weight:

Approximately 7.4 T

Overall Dimension:

12000×1800×1600 mm

Power Supply:

380V 50Hz Three‑phase

Main Motor Power:

7.5 kw

Length Tolerance:

±1 mm

Control System:

Split PLC Touch Screen

Cutting Mode:

Double Linear‑guide Hydraulic Cutting

Forming Stations:

23 Rows Rollers

Production Speed:

0‑30 m/min

Finished Effective Width:

1030 mm

Input Coil Width:

1200 / 1250 mm

Processable Thickness:

0.3‑0.6mm

Highlight:

23 rows rollers Trapezoidal Roll Forming Machine

0.3-0.6mm processable thickness C16 Roll Forming Machine

Double linear-guide hydraulic cutting Steel Wall Plate Profiling Machinery

Product Description

Efficient C16 Trapezoidal Profile Roll Forming Machine High Speed Automatic Steel Wall Plate Profiling Machinery

The C16 roll forming machine, manufactured by Dongguang Hengfu Roll Forming Machinery Co., Ltd., is a high-performance cold-forming equipment for producing YX12-103-1030 trapezoidal metal panels. It completes the whole production workflow including decoiling, manual-adjust feeding, multi-pass roll forming, fixed-length hydraulic cutting and finished-sheet output. Compatible with color-coated steel coils, the machine supports variable production speed ranging from 0-30 m/min to satisfy diverse-volume production demands for building-material processors.

Applications of Finished C16 Trapezoidal Panels

Trapezoidal metal panels produced from this line are widely-used multi-functional building materials for roofing and wall cladding.

They are the preferred roof covering for industrial plants, large warehouses, farm barns and steel-structure workshops, delivering outstanding waterproof performance and weather resistance. Besides roofing jobs, these panels can be installed as exterior wall cladding for prefabricated houses, storage sheds and market halls. Its raised trapezoidal ribs enhance structural rigidity while keeping panel weight low. The pre-painted surface offers great anti-corrosion performance against sun, rain and outdoor harsh conditions. Fast on-site installation reduces construction labor and shortens project cycles for building contractors.

Core Machine Strengths

This machine adopts heavy-duty 350H welded steel wall-plate frame with 14 mm thick carbon-steel wall boards. It is equipped with 23 forming passes. The forming rollers are made of 45# steel, going through rough-turning, fine-turning, outer-circle grinding and electroplating quenching treatment. Solid 70 mm main shafts and 1-inch chain-driven transmission ensure stable high-speed continuous running without scratching the protective coating of incoming steel strips.

It is equipped with double linear-guide hydraulic cutting assembly. Cutting blades adopt Cr12MoV alloy steel to achieve neat, burr-free cutting edges and low routine maintenance. The split cantilever-style PLC touch screen works together with rotary length counter for precise cutting control, holding length tolerance within ±1 mm. Wireless remote control brings easy and flexible field operation.

Every machine undergoes complete in-house trial-run inspection before delivery. Its overall dimension is well-suited for container loading for oversea shipment. If you want to expand your existing metal-panel product portfolio or launch new roof-wall sheet manufacturing, this robust C16 roll forming machine is a reliable workshop investment.

Technical Specifications

Item	Specification
Equipment Name	C16 Roof & Wall Panel Roll Forming Machine
Raw Material	PPGI color coated steel coil
Processable Thickness	0.3-0.6mm
Input Coil Width	1200 / 1250 mm
Finished Effective Width	1030 mm
Production Speed	0-30 m/min
Forming Stations	23 rows rollers
Cutting Mode	Double linear-guide hydraulic cutting
Blade Material	Cr12MoV
Control System	Split PLC touch screen
Length Tolerance	±1 mm
Main Motor Power	7.5 kw
Power Supply	380V 50Hz three-phase
Overall Dimension	12000×1800×1600 mm
Total Machine Weight	Approximately 7.4 T

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a professional manufacturer. You are very welcome to visit our factory at any time.

Q: What's the delivery time?

A: Normally it takes about 45 days.

Q: What service can you provide before order?

A: We provide full pre-sales service, including answers to all your questions about our machines, such as technical parameters, price, payment terms, etc. If you would like to visit our factory and inspect the machines, we can send you an invitation letter and offer you our warmest welcome.

Q: Can you finish the machine during the delivery time?

A: We will complete production on time according to the confirmed lead time.

Q: Do you have after-sale support?

A: Yes, we have experienced technicians who can provide professional technical support and advice whenever you need.

Q: Any other service?

A: We can manufacture, design, install and commission various roll forming machines, including both standard and customized ones. Machine assembly and operator training are free of charge, but the buyer is responsible for the round-trip flight tickets and accommodation for our technicians.
