1.0'' Single Chain Ceiling Roll Forming Machine With Fly Shear Cutting 0.2-0.5mm

Basic Information
Place of Origin: China
Brand Name: Saibo
Certification: CE/ISO
Model Number: YX35.8-34.5
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Suitable for ocean shipment
Delivery Time: 70 working days after received deposit
Payment Terms: T/T, L/C
Supply Ability: 300 sets per year
Detail Information
Product Name: Square Pipe Roll Forming Machine Power: 5.5KW
Size Of Purlin: YX35.8-34.5 Steel Thickness: 0.2-0.5mm
 Cutting Powe: 2.2KW Station: About 16 Stations + One Station For Rectify
Roller Material: ASTM1045 Chrome Plated Surface With Chrome Shaft Diameter: ¢56mm Solid Shaft
Decoiler: Manual Or Hydraulic Drive: By 1.0 Inch Single Chain
High Light:

Pipe Roll Forming Machine

,

Metal Stud Roll Forming Machine


Product Description

1. Specification of the material

1 Suitable Material Colored Steel plate, Galvanized steel, G550
2 Width of the raw material 110mm
3 Thickness 0.2mm-0.5mm



2. Machine Detailed Parameters

1 Roll Forming



YX35.8-34.5



2 Machine structure



Wall board structure
3 Total power

Motor power-5.5kw



4



Cutting power 2.2kw
5 Roller stations

About 16 stations + one station for rectify



6

Productivity



0-15m/min
7

Drive system



By 1.0 inch single chain
8

Diameter of shaft



¢56mm solid shaft
9

Voltage



380V 50Hz 3phases (Customized)
10

Color Of The Machine



Yellow and blue

11

Deliver Time



70 days
12

Terms Of Payment



30%T/T 70% pay before shipment



3. Profile drawing

1.0'' Single Chain Ceiling Roll Forming Machine With Fly Shear Cutting 0.2-0.5mm 0



4. The Chart of Process Flow

1.0'' Single Chain Ceiling Roll Forming Machine With Fly Shear Cutting 0.2-0.5mm 1





5. Specification of Components



(1) 3T manual decoiler

  • Adopt automatic hydraulic system for expand
  • Width of feeding: 350mm
  • Capability: 3 Ton
  • Bound of expand &fight: 380mm—520mm
  • Mode of expand &fight: inner expand &fight by manual





(2) Main Roll Forming Machine

  • Roller material:ASTM1045 chrome plated surface with chrome
  • Shaft diameter: ¢56mm material: SAE1045 with tempering
  • To avoid accidents, the driven parts will be covered with the protective cover



(3) Machine sturcture

  • Main frame by 350H beam welding
  • Machine structure: Wall board structure



(5)Hydraulic cutting system

  • Cutting after forming: Cut the sheet after roll forming to required length
  • Adopt flying shear cutting
  • Material of blade:Cr12, 58-62 HRC hardness
  • Cutting power: 2.2KW
  • Length measuring: Automatic encoder length measuring
  • Tolerance of length: +/- 1.5mm for each piece end product



(6) Computer Control Cabinet

  • Programmable setting of profile length and quantity
  • Operating system language: English and Chinese
  • Computer used to control length & quantity. Machine will automatically cut to length and stop when required quantity is achieved
  • PLC: Panasonic or customerization
