| Brand Name: | HENGFU |
| MOQ: | 1 Piece |
| Payment Terms: | 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment |
Designed for continuous industrial use, the 460 Ridge Cap Roll Forming Machine features a heavy-duty frame and high-quality components to ensure maximum durability. The chrome-plated rollers and precision shafts reduce wear and extend service life, while the optimized structure minimizes vibration during operation. This guarantees stable production and consistent product quality over time.
The 460 Ridge Cap Roll Forming Machine is built to maximize your production efficiency. With a working speed of up to 30-40 m/min, it significantly increases output while maintaining precise forming accuracy. The fully automatic system reduces manual intervention and improves workflow efficiency, making it an excellent choice for high-volume roofing production.
Investing in the 460 Ridge Cap Roll Forming Machine means investing in productivity and profitability. This machine helps reduce labor costs, minimize material waste, and improve overall production efficiency. Its user-friendly control system and low maintenance requirements make it suitable for both experienced manufacturers and new businesses.
The 460 Ridge Cap Roll Forming Machine provides a complete solution for metal roofing ridge production. From feeding to forming and cutting, the entire process is automated to ensure efficiency and consistency. It can be customized according to different profile designs and production needs, offering flexibility for various market requirements worldwide.
| Infeed Platform | Hand-cranked Feeding Stand (with Cutting Blade) |
|---|---|
| Frame Structure | Welded 350H Steel; Wall-plate Type Construction |
| Wall Plate Thickness | 14mm Carbon Steel Plate |
| Forming Stations | 14 Rows |
| Main Shaft Diameter | Ø70mm (Solid Shaft) |
| Shaft Material | #45 Steel |
| Roller Material | #45 Steel (Precision-turned, Chrome-plated, and Heat-treated) |
| Length Measurement | Rotary Counter (with Linear Slider Bracket) |
| External Voltage | 3-Phase 380V, 50Hz |
| Low-Voltage Electrical Components | Limit Switches, Contactors, Relays, etc. |
