| Brand Name: | HENGFU |
| MOQ: | 1 Piece |
| Payment Terms: | 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment |
The 50-75-100 High Speed Stud and Track Roll Forming Production Line is a brand-new, fully automated production solution, specially designed for the efficient and continuous manufacturing of drywall metal studs and tracks. It is an ideal equipment for light steel framing and interior construction systems, perfectly matching the high-efficiency and high-precision production needs of modern construction projects.
The production line adopts an integral welding structure of 35mm thick steel plates, paired with 16 forming passes to ensure stable and continuous molding. Its shafts are made of high-quality 40CR alloy steel, and it is equipped with a reliable gearbox transmission structure, which greatly enhances the overall rigidity, load-bearing capacity and long-term durability of the equipment, ensuring stable performance even under continuous high-intensity operation.
Equipped with an 11kw hydraulic pump station and a 2.3kw cutting section motor, the production line delivers stable power output and smooth operation. It supports an adjustable production speed of 0-60m/min, maintaining stable operation, precise profile dimensions and smooth surface quality even at high output speeds, effectively improving production efficiency and shortening project cycles.
The production line is integrated with an advanced PLC control system, combined with a high-speed roll forming system, servo-controlled cutting and automatic stacking, realizing a fully automated production workflow. This intelligent system achieves ultra-precise cutting and positioning, fully meeting the high accuracy requirements of modern light steel keel production, ensuring consistent product quality and easy, user-friendly operation.
| Model NO | 50-75-100 Light Steel Keel Roll Forming Machine |
|---|---|
| Condition | New |
| The machine itself | Integral welding of steel plates |
| Number of molding passes | 16 |
| Shaft material | 40CR |
| Transmission structure | Gearbox transmission |
| Frame thickness | 35mm |
| Hydraulic pump station | 11kw |
| Cutting section motor | 2.3kw |
| Production speed | 0-60m/min |
| Control system | PLC |
