Whole Plate Welding Frame Top Hat Roll Forming Machine With Mitsubishi Touch screen

Basic Information
Place of Origin: China
Brand Name: Saibo
Certification: CE/ISO
Model Number: Hat profile
Minimum Order Quantity: 1 set
Packaging Details: Suitable for ocean shipment
Delivery Time: 60 working days after received deposit
Supply Ability: negotiation
Detail Information
PLC Brand: Mitsubishi Motor Brand: Siemens
Encoder: Omron Solenoid Valve: Yuken
Transducer: YASKAWA Touch Screen: Mitsubishi
Limited Switch: Panasonic Servo Motor: Misubishi
Button: Panasonic
High Light:

Rolling Shutter Strip Making Machine

,

Corrugated Iron Sheet Making Machine


Product Description

Whole Plate Welding Frame Top Hat Roll Forming Machine 16 Stations with Rectify



High Speed Hat roll forming machine



Work flow

3T Double head hydraulic de-coiler→ Flatten→ Roll forming→ Track cutting→ finished supporter.

Whole Plate Welding Frame Top Hat Roll Forming Machine With Mitsubishi Touch screen 0

Spectification

1 Roller material Gcr15
2 Roller station 16 stations+ one station of rectify
3 Shaft diameter ¢70mm
4 Machine structure wire electrode cutting
5 Machine frame whole plate welding
6 Feeding mode Feeding is adjustable by hand wheel
7 Machine power 30kw+11kw
8 Servo power 4kw
9 Material of blade mould Cr12, 58-62 HRC hardness
10 Cutting system hydraulic track cutting system
11 Suitable material Gi, 0.8-2.0mm
12 Driven system by gear box
13 Speed 50m/min
14 Flatten system 7 rollers, Up 3 rollers, down 4 rollers
15 Machine include auto stacker
16 Machine include 3T double head hydraulic un-coiler
17 Machine include cooling system




Component

1

Roll forming system

  • Roll forming system consist of machine frame, transmission parts and roll forming rollers etc. The frame consists of base frame and wire-electrode cutting stations, base with welded sections; ensure the equipment rigidity and beautiful appearance.
2

Track cutting system

  • Profile transversal cutting device units allowing to cut the bent profile without damaging the metal coating and to assure a smooth cut included. Cut the sheet after roll forming to required length. The cutting length is controlled by PLC. Change the cutter to realize cutter different profiles.
3

Rectify device

  • Function: make the end product in straight, left and right, up and down
4

The protect cover

  • To avoid accidents, the machine will be covered with the protective mesh. It is easy to take off when need adjust machine.
5

Auto stacker

  • It is mainly used to support the finished panel.
6

Electric system

  • Adopts PLC control technology, frequency adjust speed technology, realize the automatic production.
  • System provides touch screen, which can set the order, for example length, and quantities and so on.
  • Operation type: Touch screen + button
  • Encoder calculates the number, which has calculation and measure the length function.



FAQ

1) Q: Are you manufacturer or trading company?

A: We are manufacturer and trading company .



2) Q: Do you provide installing and training overseas?

A: Overseas machine install and worker training services are optional.



3) Q: How is your after sales support?

A: We provide technical support on line as well as overseas services by skillful technicians.



4) Q: How does your factory do regarding quality control?

A: There is no tolerance regarding quality control. Quality control complies with ISO9001. Every machine has to past testing running before it's packed for shipment.



5) How can I trust you that machines pasted testing running before shipping?

A: 1) We record the testing video for your reference. Or,

2) We welcome you visit us and test machine by yourself in our factory.



6) Q: Do you have this roof panel roll forming machine in stock?

A: No, machine is made to order.
