| Brand Name: | HENGFU |
| MOQ: | 1 Piece |
| Payment Terms: | 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment |
Dongguang Hengfu Machinery Co., Ltd. manufactures advanced cold roll forming equipment, which is an efficient professional system for producing high-precision steel structural profiles. It features outstanding batch stability and long-term working reliability. Equipped with high-quality wear-resistant rollers, solid welded frame structure and high-precision forming modules, the machine maintains excellent surface smoothness, accurate size standards and stable running status in continuous production.
The whole line is configured with a fully automatic PLC intelligent control system, integrating unwinding, leveling, guiding shaping, forming processing, servo precision cutting and finished product output into a seamless continuous workflow. The user-friendly touch screen terminal allows quick parameter modification, profile specification conversion and real-time data monitoring, ensuring safe, efficient and stable whole-line production.
Our cold forming machine is applicable to galvanized steel, pre-painted steel, cold rolled steel and aluminum sheets with different specifications. Dongguang Hengfu Machinery provides personalized customized services for profile design, processing thickness, forming speed, station quantity, cutting type and high-quality electrical brands.
The cold forming process is widely adopted in roofing sheets, wall panels, C/Z/U steel purlins, metal deck plates, gutters, downpipes, door frames, cable trays and other structural components. It is an ideal professional device for construction engineering, steel structure buildings, warehouses, factories and large metal fabrication projects.
| Frame structure | Precision milling of square boxes |
|---|---|
| Number of forming rows | 14 rows |
| Wall panel thickness | 20mm |
| Material feeder | Two-hand crank feeder with pull cutter |
| Transmission method | Gear drive |
| Forming roller shaft | 50mm solid shaft |
| Cutting device type | Hydraulic shears |
| Hydraulic pump power | 4 kW |
| Tool material | CR12 Mov, hardened to 58-62 kW |
| Frame | Independent frame |
|---|---|
| Feeding device | Servo feeder |
| Feeding motor power | 1.5 kW (servo motor) |
