| Brand Name: | HENGFU |
| MOQ: | 1 Piece |
| Payment Terms: | 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment |
Dongguang Hengfu Roll Forming Machine Co., Ltd. is a professional manufacturer dedicated to designing and building high-performance roll forming and pipe production equipment. Our laser welded pipe machine integrates precision forming, advanced laser welding, straightening, and non-stop cutting into one reliable system. Made with strict manufacturing standards and premium components, this machine delivers outstanding stability, high efficiency, and consistent product quality, making it a preferred solution for pipe producers worldwide.
This machine is specially designed for 0.6mm galvanized steel strip and supports a fully automatic production flow: uncoiling, roll forming, laser welding, straightening, and non-stop cutting. The optimized process ensures stable material feeding, uniform forming, and excellent welding quality. It effectively reduces material distortion and surface damage, producing pipes with accurate dimensions, smooth welds, and ideal straightness for various industrial and construction applications.
| Material | Galvanized steel, 0.6 mm thickness |
|---|---|
| Process Flow | Decoiling → Forming → Welding → Straightening → Non-stop cutting |
| Uncoiler | Manual tension; 2.0 tons load capacity; max width 400 mm; inner diameter Φ500 |
| Forming Stands | 55 stations |
| Roller Material | Cr12 mould steel, HRC55-58 |
| Speed | 1-15 m/min (PLC inverter adjustable) |
| Laser Welder | 3 KW high configuration |
| Control System | PLC + touch screen |
| Dimension | approx. 25 m × 1.5 m × 1.5 m |
