High Precision Fence Roll Forming Machine with 25 m/min Rolling Speed and 380V / 50Hz Power Supply

Brand Name:	HENGFU
MOQ:	1 Piece
Payment Terms:	30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Max. Rolling Speed:

≤ 25 M/min

Installed Power:

12 KW

Voltage/Frequency:

380V / 50Hz ±0.4Hz

Inlet Width:

156.2mm / 125mm

Material Thickness:

0.35mm – 0.5mm

Overall Dimensions:

9m × 1m × 1.3m

Net Weight:

3100 Kg

Required Operators:

1–2 Persons

Uncoiler:

Cantilever, Manual Tension

Operation Modes:

Debug / Auto

Packaging Details:

Plastic Film & Steel Wire Fixed

Highlight:

380v fence roll forming machine

380v panel roll forming machine

50hz fence roll forming machine

Product Description

Durable Steel Fence Panel Production Line High Precision Metal Picket Cold Roll Former for Residential Construction

As a leading manufacturer in the roll forming equipment industry, Dongguang Hengfu Roll Forming Machine Co., Ltd. proudly presents its premium Fence Roll Forming Machine, a masterpiece of engineering designed to meet the rigorous demands of modern fence production. This state-of-the-art machine embodies the company's commitment to quality, efficiency, and innovation, making it the ideal solution for businesses seeking to enhance their production capabilities.

Technical Excellence

With years of expertise in cold roll forming technology, Dongguang Hengfu has crafted a machine that delivers exceptional performance while ensuring long-term reliability. The machine features impressive technical parameters that set it apart from competitors, reflecting our dedication to engineering excellence.

Parameter	Specifications
Rolling Speed	≤ 25 m/min (excluding downtime)
Installed Power	12 kW
Power Supply	380 V, 50 Hz ± 0.4 Hz
Inlet Width	156.2 mm / 125 mm
Material Thickness Range	0.35 mm - 0.5 mm
Overall Size (L×W×H)	9 × 1 × 1.3 m (excl. receiving table)
Equipment Weight	~3100 kg
Required Operators	1-2 persons
Uncoiler Type	Cantilever (manual tensioning)
Operation Modes	Debugging / Automatic

Material Versatility

One of the key advantages of our Fence Roll Forming Machine is its exceptional versatility in material handling. The machine efficiently processes materials with an inlet width of 156.2mm/125mm and a thickness range of 0.35mm to 0.5mm, accommodating various fence panel designs and specifications without extensive reconfiguration.

Operational Efficiency

Designed with the operator in mind, our Fence Roll Forming Machine prioritizes user-friendliness and low maintenance. It features both manual adjustment and automatic operation modes, providing flexibility for different production scenarios. The machine requires only 1-2 operators to run efficiently, significantly cutting labor costs while ensuring smooth workflow.

Product Gallery

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a professional manufacturer. You are very welcome to visit our factory at any time.

What's the delivery time?

Normally it takes about 45 days.

What service can you provide before order?

We provide full pre-sales service, including answers to all your questions about our machines, such as technical parameters, price, payment terms, etc. If you would like to visit our factory and inspect the machines, we can send you an invitation letter and offer you our warmest welcome.

Can you finish the machine during the delivery time?

We will complete production on time according to the confirmed lead time.

Do you have after-sale support?

Yes, we have experienced technicians who can provide professional technical support and advice whenever you need.

Any other service?

We can manufacture, design, install and commission various roll forming machines, including both standard and customized ones. Machine assembly and operator training are free of charge, but the buyer is responsible for the round-trip flight tickets and accommodation for our technicians.
